K&N Typhoon Air Intake System | 2001-2006 Honda Civic 1.6L/1.7L MT (69-1007TS)
K&N FiltersTyphoon Cold Air Intake System by K&N
The K&N 69-1007TS Typhoon cold-air intake system is a free-flowing, mandrel-bent aluminum tube air induction system designed to fit some Honda Civic VI, SI, LX, HX, EX and DX models.
The restrictive factory air filter and air intake housing are replaced by the K&N Typhoon cold-air intake which is designed to pull in outside air and dramatically reduce air flow restriction by smoothing and straightening air flow. This allows your engine to inhale a larger amount of air than the factory air intake. More air means more usable power and acceleration throughout the engine’s RPM range. The 69-1007TS cold-air intake consists of a black rubber topped K&N high-flow air filter that mounts near the passenger side wheel well directing outside air through free-flowing aluminum tubing into a short ram induction tube that delivers high volumes of clean air into the engine’s throttle body for a guaranteed power gain. The intake tubes have an attractive silver powder-coat finish that's made to last. The cold-air intake system accommodates the factory air temperature sensor and a replacement silicone crankcase vent hose.
The oversized cone shaped air filter comes with a water repellent DryCharger filter wrap to protect the filter from moisture. The air filter can be used for up to 100,000 miles before servicing is needed depending on driving conditions. This cold air intake is relatively easy to install usually in 90 minutes or less using existing factory mounting points. The tools needed are a screwdriver, pliers, ratchet set and an Allen wrench. Some Typhoon air intakes are not legal for sale or use in California and other states adopting California emission standards while others are CARB exempt and 50 state legal. Check the K&N catalog or website for vehicle applications and specific CARB status for each vehicle and air intake.
Features
- Guaranteed to increase horsepower
- Designed to improve throttle response and engine sound
- Free-flowing aluminum tubes
- Replaces entire factory air intake system
- Lasts up to 100,000 miles before service is required (depending on driving conditions)
- Easy to install, usually in 90 minutes or less
- Washable and reusable lifetime air filter
- K&N Million Mile Limited Warranty
CARB EO Number: D-269-30
Applications
- 2001 - 2006 Honda Civic VI 1.6L/1.7L
- 2002 - 2004 Honda Civic Si 1.7L
- 2001 - 2004 Honda Civic LX 1.7L
- 2001 - 2004 Honda Civic HX 1.7L
- 2001 - 2004 Honda Civic EX 1.7L
- 2001 - 2004 Honda Civic DX 1.7L
- *ONLY FITS VEHICLES W/ MANUAL TRANSMISSION*
Specifications
- Estimated HP Gain - 4.85 HP @ 6237 RPM
- Replacement Filter - RU-4950
- Air Filter Material - Cotton Gauze
- Air Filter Outlet Shape - Round
- Air Filter Height - 5.5 in (140 mm)
- Clamp Material - Stainless Steel
- Clamp Style - Regular
- Intake Pipe Color/Finish - Silver
- Intake Pipe Material - Aluminum
What's In The Box?
- 1 - K&N Air Filter (RU-4950)
- 2 - K&N Typhoon Intake Tubes
- 2 - Silicone Couplers
- 5 - Stainless Steel Clamps
- Mounting Hardware
References
Warranty
- K&N Million Mile Limited Warranty
