K&N HP-1004 Oil Filter

Originally developed for demanding race applications, K&N's Premium Wrench-Off Oil Filter has become a favorite among consumers for its durability and easy removal. Most of our automotive and marine oil filters come with a 1 inch nut welded to the top of the canister so they can be easily wrenched-off with a standard tool. To satisfy the demands of racers, our oil filter has many features over and above the requirements of most vehicles. We use thicker canister walls for extra strength and durability which reduces the risk of damage from loose rocks and debris. The drilled hole on the nut provides for safety wire attachment. Our oil filters also use a resin impregnated cellulose filter media. This allows for higher flow rates while providing outstanding filtration.

Features

• O/E replacement oil filters for most cars, trucks, SUV's, motorcycles, & ATV's
• 1 inch exposed nut designed for easy oil filter removal
• Heavy duty construction for extreme conditions
• Anti-drain back valve (where applicable) eliminates dry starts, prevents oil from draining back into crankcase during engine shutdown

Specifications

• Anti Drain Back Valve Yes
• Bypass Valve Yes
• Filter Material High Flow Premium Media
• Gasket Material Nitrile Rubber
• Height 3.406 in (87 mm)
• Outside Diameter 3.156 in (80 mm)
• PSI Relief Valve 11-17
• Removal Nut Yes
• Style Canister
• Thread Specification M20 x 1.5-6H
• Weight 0.8 lb (0.3 kg)
• Removal Nut Size 1 inch

Applications

• 2008-2015 Mitsubishi Evo X
• 1999-2009 Honda S2000
• 2013-2016 Scion FR-S
• 2013-2019 Subaru BRZ
• 2015-2019 Subaru WRX
• Many Kia and Hyundai applications
• Many Honda Applications 1988-2000

Part Number Cross Reference

• AC Delco PF1127
• AC Delco PF1230
• AC Delco PFH1014
• AC Delco PFR3004
• Champ Labs. PH2808
• Fram PH2871
• Fram PH3593A
• Fram PH3917
• Fram PH4870
• Fram PH6607
• Fram PH6811
• Fram PH7317
• Fram PH9688
• Fram TG3593A
• Fram TG6607
• Fram TG7317
• Fram TG9688
• Fram XG3593A
• Fram XG6607
• Fram XG7317
• Fram XG9688
• Hyundai 2630035503
• Hyundai 2630035504
• Kia 2630035503
• Mitsubishi MZ690116
• Mobil One M1104A
• Motorcraft AFL27A
• Motorcraft FL799
• Motorcraft FL810
• Onan 1220833
• Purolator L14459
• Purolator L24458
• Scion SU00300311
• Subaru 15208AA031
• Subaru 15208AA130
• Subaru 16546JB000
• SuperTech ST9688
• WIX 51334
• WIX 51568

What's In The Box?

• (1) Valve

Warranty

• Manufacturer Standard Warranty

Resources

• Installation Manual
