JW Speaker: 735T-12/32V Lamp - BLACK - Trapezoid Beam w/Harness (1706581)

High performance optics: solid-state electronics, and die-cast aluminum housing make this lamp extremely resistant to shock, vibration, and corrosion.

Features

• Height: 137.16 mm / 5.4 in
• Width: 144.27 mm / 5.68 in
• Depth: 66.04 mm / 2.6 in
• Shape: Oval
• Outer Lens Material: Polycarbonate
• Outer Lens Color: Clear
• Housing Material: Die-Cast Aluminum
• Housing Color: Black
• Mounting Hardware Description: (x1) 5/16"-18 x 0.58" Mounting Bolt
• Mounting Type Universal: Pedestal Mount
• Minimum Operating Temperature: -40 degC / -40 degF
• Maximum Operating Temperature: 65 degC / 149 degF
• Connector or Wiring: Integrated 2-Pin Deutsch Weather-Proof Socket (DT04-2P)
• Mating Connector: 2-Pin Deutsch Weather-Proof Plug (DT06-2S)
• Product Weight: 1.87 lbs / 0.85 kgs
• Shipping Weight: 1.87 lbs / 0.85 kgs
• Input Voltage: 12-24V DC
• Operating Voltage: 10-36V DC
• Red Wire: Positive
• Black Wire: Negative
• Current Draw: 3.50A @ 12V DC, 1.75A @ 24V DC

Applications

• Universal

What's In The Box?

• HOUSING: 1x JW Speaker Model 735 LED Oval Work Light
• PART NUMBER: 1706571, 1706821, 1707051, 1706801, 1706581, 1706811, or 1707041
• OTHER: Instruction Card + JW Speaker Sticker

References

• Installation Instructions

Warranty

• WARRANTY: Lifetime Limited
