Hybrid Racing Cold Air Intake System | Multiple Honda/Acura Fitments (HYB-CAI-01-14)

Cold Air Intake System by Hybrid Racing

Designing an intake system with a set of guidelines isn't hard to achieve. However, building an intake system that not only fits every engine combination while allowing that setup to produce more power is. We chose to narrow that field and focus on what we consider to be the best recipe for power gains. With the success of our eighth generation Civic Si intake system we used what we learned and created this system for our fellow DC5 RSX owners.

Due to size constraints inside of the DC5 chassis, the intake system was restricted to a 3-inch design. Combined with our high-flow velocity air filter, this Cold Air Intake System has shown gains of up to 10% (5-10hp) across the powerband compared to a short ram system while significantly reducing intake air temperatures. Don't want to relocate your battery? No problem. The Hybrid Racing RSX intake allows for the battery to stay in the OEM location

The intake requires a 70mm or larger throttle body and the RBC/RRC style intake manifolds. Fitment or compatibility with an OEM PRB intake is not guaranteed. Slight trimming of the LH inner fender lining is required and the removal or relocation of the OEM windshield washer bottle is needed. Alterations to cars running OEM Type R brake cooling ducts may be necessary. The included radiator hose fits the K20A/A2/A3/Z1 water neck. It may not fit the K20Z3/K24 water neck.

Features

• Full Silicone Construction
• Most powerful RSX Intake on the market
• True 3-inch tube design

Benefits

• Shows Gains of up to 10% (5-10hp)
• Improved airflow and filtration efficiency

Please Note: Requires the use of 70mm Throttle Body. Requires the RBC intake manifold. Modification to cars equipped with foglights may be required. Battery relocation may be required.

Applications

• 2002 - 2006 Acura RSX/Honda Integra (without brake cooling ducts)
• 2001 - 2005 Honda Civic Non-Si (K-Swapped)
• 2002 - 2005 Honda Civic Si

What's In The Box?

• 1 - 3" Hybrid Racing Silicone Cold Air Intake Tube
• 1 - Velocity stack filter
• 1 - Silicone Upper Radiator Hose (for PRB style coolant neck)
• 1 - Valve cover breather filter
• 1 - Lower filter bracket
• 1 - Anti-vibration clamp
• 1 - Stainless T-bolt clamp
• 2 - Silicone hoses for breather connections
• 2 - Machined aluminum push-in fittings
• 5 - Hose Clamps
• 2 - Bolts
• 3 - Washers

References

• Installation Instructions

Warranty

• Manufacturer Standard Warranty
