SpeedFactory Racing High Performance MLSS-HP Head Gaskets | 1990-2001 Acura Integra, 1999-2000 Honda Civic Si, and 1997-2000 Honda Civic Type-R (SF-02-200)

1990-2001 Acura Integra, 1999-2000 Honda Civic Si, and 1997-2000 Honda Civic Type-R High-Performance MLSS-HP Head Gaskets by SpeedFactory

SpeedFactory Racing is proud to release our line of high-performance Honda/Acura B-Series VTEC MLS head gaskets!

These MLS gaskets have been purpose-built to provide an excellent seal on ALL B-Series VTEC applications, from factory setups to high compression/nitrous / turbocharged / supercharged engines.

Our gasket utilizes a 4-layer design with specialized embossments that increase active combustion sealing height, ideal for high-output engines that experience high levels of head lift/movement. The thickness is ideal for use with O-rings in extremely high-output applications that require it for reliable combustion sealing. We've also incorporated a unique internal silicone bead on the oiling passages for improved sealing.

When used in combination with our Extreme Duty L19 Head Stud Kit, our gaskets have been real-world tested to 1000HP with excellent results in non-O-ringed blocks (and up to 1400hp+ when used with O-ringed sleeved blocks). Note that this is NOT a stopper ring-type design.

We have found over years of trying many different B-Series MLS gasket designs that once you reach an output level that eclipses what a non-stopper ring MLS gasket will reliably hold, adding a stopper ring only provides limited improvement and O-ringing the cylinder head or block becomes a necessity for a reliable combustion seal. The stopper ring becomes more of a hindrance to O-ring placement and function at that point and we have had much better success running O-rings with a non-stopper design.

Another unique feature is enlarged head stud holes for compatibility with 1/2” head studs (the 2 locating dowel holes remain OEM sized and are the only holes that need to be modified if running 1/2" head studs, greatly reducing the time & effort required during engine assembly). We have been reliably running these gaskets on wet deck Bullet Billet blocks which utilize 1/2" head studs at 1400+whp.

Features

• MLSS-HP (Multiple Layer Stainless Steel + Silicone Bead) Head Gasket optimized for high-performance use
• 4-layer MLS design with specialized embossment increases active combustion sealing height, ideal for forced induction engines that experience high levels of head lift/movement.
• Unique internal silicone elastomeric sealing bead around oiling passages for improved fluid sealing.
• High-performance elastomeric coating to ensure the best possible seal by compensating for surface irregularities.
• 1/2" head stud compatible.
• OE quality, OE certified manufacturer (ISO 9001, ISO/TS16949, ISO 14001 certified).
• Constructed from high-quality materials
• Available Sizes:
• 81.50mm (Use for 81.00-81.75mm/3.218” maximum bore)
• 82.00mm (Use for 82.00-82.25mm/3.238” maximum bore)
• 83.00mm (Use for 83.00-83.25mm/3.277” maximum bore)
• 84.00mm (Use for 84.00-84.25mm/3.316” maximum bore)
• 84.50mm (Use for 84.50-84.75mm/3.336” maximum bore)
• 85.00mm (Use for 85.00-85.25mm/3.356” maximum bore)
• 040”/1.016mm thickness

Applications

• 1989-1991 Honda CRX SiR
• 1989-1994 Honda Civic SiR
• 1992–1994 Honda Civic SiRII
• 1996–1998 Honda Civic SiR
• 1996–1998 Honda Civic SiRI
• 1997–2000 Honda Civic Type R
• 1999-2000 Honda Civic Si
• 1994-1997 Honda Del Sol
• 1992–2001 Acura Integra GS-R
• 1990–2001 Acura Integra RS
• 1990–2001 Acura Integra LS
• 1990–2001 Acura Integra GS
• 2000-2001 Acura Integra Type R
• 1996-2001 Honda CR-V

What's In The Box?

• 1 - Head Gasket

Warranty

• SpeedFactory's Standard Limited Warranty
