Precision Turbo Street & Race 6766 Billet JB CEA Turbocharger - 935WHP (PTB305-6766)

PTE 6766 Journal Bearing Turbo

We know you want to be the best both on the track and off. Whether you're a diehard racer or just looking to boost your daily driver's performance, Precision Turbo and Engine has what you need. For exceptional power and unbeatable technology at an affordable price, PTE can help you find the perfect turbocharger for your unique setup.

Features

• Exclusive CEA® compressor wheel machined from a 2618-aluminum forging
• Higher efficiency and faster transient response for maximum power and performance
• 67mm inducer compressor wheel
• Compressor cover options - "E" compressor cover 3.0" inlet/2.0" outlet - "S" compressor cover 4.0" inlet/2.5" outlet - "Ported S" compressor cover 4.0" inlet/2.5" outlet - "H" compressor cover 4.0" inlet/3" outlet - "Ported H" compressor cover 4.0" inlet/3" outlet
• 66mm, 76 trim turbine wheel
• Turbine housing options - T3 .63 or .82 A/R with 4 bolt (2.5") discharge - T3 .63 A/R with 5 bolt discharge (with or without wastegate hole) - T3 .63 or .82 A/R with 3" OD (outer diameter) V-Band discharge - V-Band inlet .82 A/R with V-Band discharge - T4 Tangential .58, .68, .81, or .96 A/R with 3 5/8" OD (outer diameter) V-Band discharge - T4 Divided .84, 1.0, 1.15, or 1.32 A/R with 3 5/8" OD (outer diameter) V-Band discharge - Buick .63 or .85 A/R - GMC Syclone/Typhoon .85 A/R - K26 .82 A/R
• Available with either a Hydrodynamic 360° thrust bearing system, or an Air-cooled, dual ceramic ball-bearing center housing rotating assembly (CHRA)

Relevant Part Numbers

• PTB305-6766, PTB505-6766, PTB605-6766, PTB655-6766
• Turbine Housing Clamp & Flanges Reference
• Compressor Cover Reference

Applications

• Universal

What's in the box?

• 1 Turbocharger

Installation

• Click Here

Warranty

• Precision Turbo Limited Warranty
