HKS HIPERMAX S Full Kit | Mitsubishi Evo X CZ4A (80300-AM001)

HIPERMAX S CZ4A Full Kit by HKS

HKS will integrate and renew the three existing MAXIV GT Series into HIPERMAX S. 9 years have passed since the launch of MAXIVGT, and during that time, we have developed new technologies. It will be a new series that has all three conventional model's characteristics, and been evolved by damping force characteristics, durability and beauty. The HIPERMAX S Series offers the best ride in HKS suspension history.

Features

• Spring Rate [N/mm(kgf/mm)]: F=98(10.0) | R=69(7.0)
• Spring Length (mm): F=220 (Straight Barrel Type) | R=220 (Straight Barrel Type)
• Height at Factory (Upper-Lower): F=-36(-19 to -60) | R=-19(0 to -57)
• Upper Mount: F=Rubber | R=Rubber
• Spring Rate Change at Factory [Changeable Spring Rate N/mm(kgf/mm)]: F=-20 (2) | R=-20 (2)

Benefits

• Dual PVS
• Wide Range Damping Force Adjustment Mechanism
• Evolution of Bump Stop Rubber
• Low Friction Technology
• Single Tube
• 30 Levels Adjustable Damping
• Shock-Body Length Adjustable
• Special Oil
• PNE Coating
• Dual Pre-Load Valve System
• Aluminum Bracket
• Rubber Upper Mount
• Spec. Change Available
• Overhaul Available

Applications

• 2008 - 2016 Mitsubishi Lancer Evolution

What's In The Box?

• 1 - HIPERMAX S CZ4A Full Kit

Warranty

• Manufacturers Standard Warranty
